96W 24V Dimmable Electronic Transformer – Triac/ELV/MLV – UL Listed | 120V AC OTM-TD96-JA24
96W 24V Dimmable Electronic Transformer – Triac/ELV/MLV – UL Listed | 120V AC OTM-TD96-JA24
Roll over image to zoom in Click on image to zoom
96W 24V Dimmable Electronic Transformer – Triac/ELV/MLV – UL Listed | 120V AC OTM-TD96-JA2496W 24V Dimmable Electronic Transformer – Triac/ELV/MLV – UL Listed | 120V AC OTM-TD96-JA24

96W 24V Dimmable Electronic Transformer – Triac/ELV/MLV – UL Listed | 120V AC OTM-TD96-JA24

SKU: STL-OTM-TD96-JA24
Price:
$69.99
Motion Sensor Specsheet
Spec Sheet

Description

  • Advanced Dimming Technology: Supports Triac, ELV, and MLV dimming with a 0-100% dimming range.
  • High Efficiency & Low THD: Operates at 88% efficiency with THD < 20%, ensuring stable power output.
  • Versatile Installation: Suitable for damp, dry, and wet locations, ideal for LED strips, residential, and commercial lighting.
  • Built-in Safety Protections: Includes short-circuit and overload protection, automatically recovering from faults.
  • Certified & Durable: UL Listed, Class 2, Class P, Type HL, SELV, and RoHS compliant, backed by a 5-year warranty.
Product Attributes
Model Number OTM-TD96-JA24 Rated Power 96W
Rated Voltage 24V Rated Current 4.0A
Voltage Tolerance ±1.5V Input Voltage 120V AC
Frequency Range 47-63Hz Power Factor 0.94@120V AC
Efficiency 88% @ 120V AC Total Harmonic Distortion (THD) <20% @ Max Load
AC Current 0.9A Leakage Current <0.5mA @ 120V AC
Operating Temperature -40°C to 60°C Storage Temperature -40°C to 90°C
Certification UL Listed, Class 2, Class P, Type HL, SELV, RoHS
Dimensions 127 × 82 × 41.8 mm (5 × 3.22 × 1.64 inches)
Application LED Strips, LED Tape, LED Modules, Residential & Commercial Lighting
Protection Short-circuit & Overload Protection (Auto Recovery)
Warranty 5 Years
