200W 24V Dimmable Electronic Transformer Commercial Grade Triac/ELV/MLV – UL Listed | 120V AC
200W 24V Dimmable Electronic Transformer Commercial Grade Triac/ELV/MLV – UL Listed | 120V AC
Roll over image to zoom in Click on image to zoom
200W 24V Dimmable Electronic Transformer Commercial Grade Triac/ELV/MLV – UL Listed | 120V AC200W 24V Dimmable Electronic Transformer Commercial Grade Triac/ELV/MLV – UL Listed | 120V AC

200W 24V Dimmable Electronic Transformer Commercial Grade Triac/ELV/MLV – UL Listed | 120V AC

SKU: STL-OTM-TD200-JA24
Price:
$119.99
Motion Sensor Specsheet
Spec Sheet

Description

  • Optimized for High-Power Applications: 200W output with stable constant voltage operation.
  • Superior Dimming Range: Achieves 0-100% flicker-free dimming with Triac, ELV, and MLV dimmers.
  • Reliable for Harsh Environments: Built for damp, dry, and wet locations, ideal for outdoor LED setups.
  • Auto-Protection & Recovery: Overload and short-circuit protections ensure long-term reliability.
  • Energy-Efficient & Certified: 90% efficiency, UL Listed, Class P, Type HL, RoHS approved, with 5-year coverage.
Product Attributes
Model Number OTM-TD200-JA24 Rated Power 200W
Rated Voltage 24V Rated Current 8.340A
Voltage Tolerance ±1.5V Input Voltage 120V AC
Frequency Range 47-63Hz Power Factor 0.94@120V AC
Efficiency 88% @ 120V AC Total Harmonic Distortion (THD) <20% @ Max Load
AC Current 0.9A Leakage Current <0.5mA @ 120V AC
Operating Temperature -40°C to 60°C Storage Temperature -40°C to 90°C
Certification UL Listed, Class 2, Class P, Type HL, SELV, RoHS
Dimensions 127 × 82 × 41.8 mm (5 × 3.22 × 1.64 inches)
Application LED Strips, LED Tape, LED Modules, Residential & Commercial Lighting
Protection Short-circuit & Overload Protection (Auto Recovery)
Warranty 5 Years
