Addressable SPI Pixel Control: Unlike conventional wall washers with fixed static output, the RL48-SPI is a pixel-addressable fixture driven by SPI (TTL) digital signal — enabling dynamic per-pixel color animation, chasing effects, and segmented lighting across the fixture's full length when controlled by a MiBoxer SPI controller.
-
Part of the MiBoxer SPI Ecosystem: Designed to operate as a subordinate SPI lighting device — connect directly to any compatible MiBoxer SPI controller output (SPIR5, SPIW5-4, SPI-WL4, SPIR3, etc.) for full program-driven pixel control without any additional wiring or pairing steps.
-
Full RGB Color Output: Delivers a rich, saturated RGB color spectrum across the entire fixture length — ideal for dramatic architectural washing, façade animation, landscape feature accents, and entertainment-grade color effects.
-
48W High-Output Fixture: A powerful 48W wall washer delivering high lumen output for impactful illumination of large vertical surfaces, building facades, bridges, retaining walls, and landscape features.
-
Narrow Beam Wall Wash Optics: Features a 15° × 60° beam angle — the same precision optic used across MiBoxer's RL series — delivering a focused, even wash of light across vertical surfaces with minimal spill.
-
IP66 Weatherproof Rated: Full IP66 dust and water ingress protection — sealed to operate in rain and outdoor environments year-round for permanent architectural installations.
-
Die-Cast Aluminum Housing: Built from high-grade aluminum alloy with anodized finish for corrosion resistance and rapid heat dissipation — ensuring long lifespan even in harsh outdoor conditions.
-
Stalinite Lens Surface: Optical-grade tempered glass lens delivers high light transmittance with wide-angle diffusion for a smooth, even wash — minimizing hot spots across the illuminated surface.
-
180° Adjustable Mounting Bracket: Includes a fully rotatable bracket allowing precise beam angle adjustment up to 180° — adaptable to wall, ground spike, or surface mount configurations.
-
Designed for Long Runs & Multi-Fixture Installations: Multiple RL48-SPI units can be daisy-chained from a single SPI controller output, with the MiBoxer SPI-PA4 amplifier used to extend runs when needed — making it suitable for large-scale linear architectural projects.
The MiBoxer RL48-SPI 48W SPI Wall Washer brings the power of addressable pixel control to architectural outdoor lighting. By accepting a direct SPI (TTL) signal from any MiBoxer SPI series controller, it enables dynamic, program-driven RGB animation across building facades, landscape features, bridges, and outdoor entertainment environments — all within a rugged, IP66-rated aluminum housing engineered for permanent installation.
