Description
This 50W/40W/30W LED flood light features field-selectable wattage and 3 CCT color temperature options (3000K/4000K/5000K), delivering up to 6,000 lumens at 120 lumens per watt. Built with an ADC12 die-cast aluminum housing in a dark bronze finish, the fixture is rated IP65 for wet locations and includes a built-in photocell for automatic dusk-to-dawn operation. Available with interchangeable trunnion or knuckle mount brackets, it is ETL and DLC listed and backed by a 5-year warranty.
Key Features
50W/40W/30W
Selectable
3CCT
30K/40K/50K
Built-In
Photocell
IP65
Waterproof
Specifications
| General | |
|---|---|
| Selectable Wattage | 50W / 40W / 30W |
| CCT (Color Temperature) | 3000K / 4000K / 5000K (Selectable) |
| Mounting Options | Trunnion or Knuckle (Interchangeable) |
| Finish | Dark Bronze |
| Certifications | ETL / DLC Listed |
| Warranty | 5 Years |
| Electrical | |
| Input Voltage | AC 120–277V |
| Power Factor | >0.9 |
| Dimming | 0–10V (Purple / Pink Wires) |
| Photocell | Built-In (Dusk-to-Dawn) |
| Optical | |
| Luminous Efficacy | 120 LM/W |
| Lumen Output | 6,000 / 4,800 / 3,600 Lumens |
| CRI | >80 |
| Beam Angle (NEMA) | 7H × 7V (130°+ Wide Flood) |
| LED Chip | SMD 2835 |
| Physical | |
| Housing Material | ADC12 Die-Cast Aluminum |
| IP Rating | IP65 |
| Operating Temperature | -40°F to +113°F |
| Lifespan | >50,000 Hours |
| Dimensions (Knuckle) | 10.14" × 2.59" × 8.8" |
| Dimensions (Trunnion) | 10.14" × 2.59" × 8.11" |
| Weight | 2.86 lbs |
Features
- Field-selectable wattage allows the installer to choose between 50W, 40W, or 30W output by adjusting the internal DIP switch, reducing the need to stock multiple SKUs for different applications.
- Three selectable color temperatures — 3000K (warm white), 4000K (neutral white), and 5000K (daylight) — are set via the same internal switch, giving full control over light appearance before installation.
- The built-in photocell enables automatic dusk-to-dawn operation, turning the fixture on at sunset and off at sunrise without external timers or controls.
- 0–10V dimming capability is supported through dedicated purple and pink wiring leads, allowing integration with building management systems or compatible dimmers.
- The ADC12 die-cast aluminum housing provides effective heat dissipation, keeping the LED junction temperature below 65°C and contributing to less than 3% light depreciation over the first 1,000 hours of operation.
- Structural waterproofing achieves an IP65 rating, making the fixture suitable for exposed outdoor installations in rain, snow, and dust conditions.
- The trunnion and knuckle mount brackets are interchangeable, allowing the same fixture to be wall-mounted, pole-mounted, or surface-mounted depending on the project requirements.
- Precise angle markings on both bracket types ensure consistent, repeatable aiming across multi-fixture installations.
- Universal 120–277V input voltage supports both residential and commercial electrical systems without the need for an external transformer.
- ETL listed for safety and DLC listed for utility rebate eligibility, with a 5-year manufacturer warranty.
Applications
- Building facade and architectural accent lighting for commercial properties, hotels, and event venues
- Parking lot perimeter and security lighting on walls, poles, or bollards
- Church, school, and municipal building exterior illumination
- Retail storefront and signage wash lighting
- Loading dock, service entrance, and warehouse exterior security lighting
- Landscape and hardscape flood lighting for pathways, trees, and garden features
- Sports court and recreational area lighting for residential and community facilities
- Bridge, overpass, and public infrastructure accent and safety lighting
