Description
This 25W LED bullet flood light is purpose-built for landscape and outdoor area lighting. Selectable wattage — 15W, 20W, or 25W — and three field-switchable color temperatures let one fixture cover a wide range of installations without stocking multiple SKUs. The integrated dusk-to-dawn photocell handles on/off automatically, the angle-adjustable knuckle bracket aims precisely at any target, and the heavy die-cast aluminum housing with bronze powder-coat finish holds up through rain, heat, and cold. UL, CUL, and DLC Listed with a 5-year warranty.
Key Features +
15W / 20W / 25W
Selectable
3000K / 4000K
/ 5000K CCT
Integrated
Photocell
Up to 3,200
Lumens
Angle-Adjustable
Knuckle Mount
UL / CUL
/ DLC Listed
Specifications +
| General | |
|---|---|
| Model No. | AST-FL17-25WBH5DA1 |
| LED Chip | Lumileds 2835 |
| LED Driver | UL Listed BHE Brand |
| Equivalent Replacement | 50–100W MH / HPS |
| Electrical | |
| Wattage (Selectable) | 15W / 20W / 25W |
| Lumen Output (at 25W) | 3,200 lm |
| Efficacy | 128 lm/W |
| Color Temperature (Selectable) | 3000K / 4000K / 5000K |
| CRI | >80 |
| Input Voltage | 120–277VAC |
| Dimming | 0–10V |
| Power Factor | 0.9 |
| Optical | |
| Beam Angle | 38° |
| Light Distribution | 120D |
| Lens | High-Quality Tempered PC |
| Physical | |
| Housing | Heavy Die-Cast Aluminum, Bronze Powder-Coat Finish |
| Mounting | Angle-Adjustable Knuckle Bracket |
| Operating Temperature | -40°C to +45°C |
| Photocell | Integrated Dusk-to-Dawn |
| Certifications | UL, CUL, DLC |
| Warranty | 5 Years |
Features +
- Selectable wattage — flip between 15W, 20W, and 25W in the field without swapping fixtures, making a single SKU suitable for paths, accent trees, building facades, and area flood applications at different throw distances
- Three field-switchable color temperatures — 3000K warm white, 4000K neutral, and 5000K daylight — selectable at installation to match the landscape palette or site requirement
- Integrated dusk-to-dawn photocell eliminates manual switching and timers — the fixture turns on automatically at dusk and off at dawn with no additional controls or wiring required
- 3,200 lumens at 25W with 128 lm/W efficacy from premium Lumileds 2835 chips — soft, uniform output with no flicker and no humming from instant-start operation
- 0–10V dimming compatible for installations requiring additional control beyond the photocell
- 38° beam angle concentrates output precisely, making this fixture effective for uplighting trees, flagpoles, signage, and architectural features without excessive spill
- Angle-adjustable knuckle bracket allows precise aiming across a wide range — reposition at any time without tools to redirect the beam as landscaping matures
- Heavy die-cast aluminum housing with bronze powder-coat finish handles temperature swings from -40°C to +45°C and resists corrosion in outdoor environments
- High-quality tempered PC lens provides durable, impact-resistant light transmission and protects the LED array from debris and moisture
- Replaces 50–100W metal halide and HPS fixtures at a fraction of the energy draw — mercury-free and fully RoHS compliant
- UL and CUL Listed with a UL-listed BHE brand driver; DLC Listed for utility rebate eligibility
Applications +
- Tree and shrub uplighting in residential and commercial landscapes
- Flagpole and monument accent lighting
- Building facade and architectural feature wash lighting
- Pathway, walkway, and garden border illumination
- Outdoor basketball courts, tennis courts, and recreational fields
- Parking lot perimeter and entry area lighting
- School playgrounds, stadiums, and community plazas
- Warehouses, factory yards, and commercial outdoor work areas
- Highway toll stations and meeting/exhibition outdoor areas
