160W LED Dimmer + Driver Combo Switch – Dimming or Dimming + CCT, 24VDC, 3-Way

SKU: STL-BD160-24-D
Model: Dimming
Price:
$139.99
Motion Sensor Specsheet
Spec Sheet

Description

  • Integrated Dimmer & CCT Slider Combines constant voltage LED driver, smooth dimming control, and built-in CCT slider in one unit, allowing precise brightness and color temperature adjustment without external controllers.

  • Smooth Flicker-Free Performance Supports 0.3%–100% dimming using 16kHz PWM output with gamma 2.2 curve, ensuring flicker-free operation and stable CCT transitions for professional lighting applications.

  • Stable 24V Constant Voltage Output Provides regulated 24V output with fine voltage adjustment up to 26V, ensuring reliable operation and optimized performance for compatible 24V CCT LED strip systems.

  • Advanced Safety Protection System Features built-in short-circuit, overload, and over-temperature protection with automatic recovery, safeguarding connected LED loads while extending driver lifespan and operational reliability.

  • Indoor Dry and Damp Applications Designed with natural air convection cooling and high efficiency, making it suitable for architectural, commercial, and residential indoor LED installations in dry and damp locations.

Product Type LED Driver with Dimmer & CCT Slider Output Voltage DC 24V
Maximum Power 160W Rated Current 6.67A
Input Voltage 120VAC Input Frequency 60Hz
Dimming Range 0.3%–100% Dimming Method PWM
PWM Frequency 16kHz Dimming Curve Gamma 2.2
Voltage Adjustment 24–26V Efficiency Up to 94.5%
Power Factor 0.99 @ Full Load THD ≤10%
Protection Type Short Circuit / Overload / Over Temperature Cooling Method Natural Air Convection
Operating Temperature -40°C to +60°C Environment Dry & Damp Locations
